17/24 Circuit-breakers, switch-disconnectors
Circuit-breakers, electronic releases, 3 pole
2010 CA08103002Z-EN
www.eaton.comFixed mounting
with screw terminals
Switching
capacity
400/415 V
50/60 Hz
Rated current =
Rated
uninterrupted
current
Setting range
Part no.
Article no.
Price
See price
list
Overload
releases
Short-circuit releases
Non-delayed Delayed
I
cu
I
n
= I
u
I
r
I
i
= I
n
x … I
sd
= I
r
x …
kA
A
A
Systems protection, cable protection, selectivity, generator protection
Normal switching capacity
50
100
50-100
1200 A fixed 2-10
NZMN2-VE100
259122
S
160
80-160
1920 A fixed 2-10
NZMN2-VE160
259123
S
250
125-250
3000 A fixed 2-10
NZMN2-VE250
259124
S
250
125-250
2-11
2-10
NZMN3-VE250
259131
S
400
200-400
2-11
2-10
NZMN3-VE400
259132
S
630
315-630
2-8
1.5-7
NZMN3-VE630
259133
S
630
315-630
2-12
1.5-7
NZMN4-VE630
265768
S
800
400-800
2-12
2-10
NZMN4-VE800
265769
S
1000
500-1000
2-12
2-10
NZMN4-VE1000
265770
S
1250
630-1250
2-12
2-10
NZMN4-VE1250
265771
S
1600
800-1600
2-12
2-10
NZMN4-VE1600
265772
S
High switching capacity
150
100
50-100
1200 A fixed 2-10
NZMH2-VE100
259125
S
160
80-160
1920 A fixed 2-10
NZMH2-VE160
259126
S
250
125-250
3000 A fixed 2-10
NZMH2-VE250
259127
S
250
125-250
2-11
2-10
NZMH3-VE250
259134
S
400
200-400
2-11
2-10
NZMH3-VE400
259135
S
630
315-630
2-8
1.5-7
NZMH3-VE630
259136
S
85
630
315-630
2-12
1.5-7
NZMH4-VE630
265773
S
800
400-800
2-12
2-10
NZMH4-VE800
265774
S
1000
500-1000
2-12
2-10
NZMH4-VE1000
265775
S
1250
630-1250
2-12
2-10
NZMH4-VE1250
265776
S
1600
800-1600
2-12
2-10
NZMH4-VE1600
265777
S
Earth fault protection
50
250
125-250
2-11
2-10
NZMN3-VE250-T
110891
S
400
200-400
2-11
2-10
NZMN3-VE400-T
110892
S
630
315-630
2-8
1.5-7
NZMN3-VE630-T
110893
S
150
250
125-250
2-11
2-10
NZMH3-VE250-T
110897
S
400
200-400
2-11
2-10
NZMH3-VE400-T
110898
S
630
315-630
2-8
1.5-7
NZMH3-VE630-T
110899
S
I
I
NZM...VE
