4/110 Cam switches, switch-disconnectors
Switch-disconnectors
2010 CA08103002Z-EN
Surface mounting
P3-63/I4
Surface mounting main switches/safety
switches
P3-63/I4/SVB
P3-63/I4/SI
T5B-.../I4/SI
Drilling dimensions
Surface mounting
P3-100/I5
Surface mounting main switches/safety
switches
P3-100/I5/SVB
P3-100/I5/SI
T5-.../I5/SI
Drilling dimensions
a23 95 29
b23
95 44
193
142
M5
M25
M32 M20
a23 125 37 125 44
233
182
M5
M25
M50 M20
b23
Part no. a2 a3 a4 a21 a22 a23 a31 a32 a33 b2 b3 b21 b22 b23 b24 b31
P3-63/I4
P3-100/I5
87
87
72
72
71.5
71.5
87
87
87
87
160
200
18
18
15
15
114
114
87
87
83
83
87
87
27
27
240
280
35.5
35.5
60
60
Part no. c2 c3 c20
≧/≦
c20 with
≦ 4
ZAV/ZVV
c21 c22 c23 c24 c25 c27 c28 c31 c32 c33
P3-63
P3-100
59
59
82
82
103 – 118
103 – 118
218
218
37
37
41
41
63
63
81
81
65
65
44
44
125
125
25
25
25
25
37
37
P3
