4/42 Cam switches, switch-disconnectors
Control switches – step switches
2010 CA08103002Z-EN
www.eaton.comControl switches– step switches
Flush mounting
1)
Center mounting
1)
Contact sequence
Front plate
no.
Main
contacts
Front IP65
Front IP65
Pole
Part no.
Article no.
Price
See price
list
Std. pack
Part no.
Article no.
Price
See price
list
Std. pack
N/O
Step switches
With black thumb-grip and front plate
One contact closed per step
Without overlap
With 0 (Off) position
1
T0-1-8240/E
034105
1 Off
T0-1-8240/EZ
043597
1 Off
1
T0-2-8241/E
050716
T0-2-8241/EZ
053089
1
T0-2-8242/E
067327
T0-2-8242/EZ
069700
1
T0-3-8243/E
081565
T0-3-8243/EZ
083938
1
T0-3-8244/E
095803
T0-3-8244/EZ
098176
3
T0-3-8280/E
034106
T0-3-8280/EZ
036479
3
T0-5-8281/E
048344
T0-5-8281/EZ
050717
3
T0-6-8282/E
062582
T0-6-8282/EZ
064955
Information relevant for export to North America
1)
Product Standards
UL 508; CSA-C22.2 No. 14-05; IEC/EN 60947-3; CE marking
UL File No.
E36332
UL CCN
NLRV
CSA File No.
12528
CSA Class No.
3211-05
NA Certification
UL Listed, CSA certified
Suitable for
Branch circuits
Degree of Protection
IEC: IP65; UL/CSA Type 3R, 12
1
2
3
4
