2010

CA08103002Z-EN

www.eaton.com

22/26

Symbol

Meaning

DF

Duty factor

I

cm

Rated short-circuit making capacity

I

cn

Rated short-circuit breaking capacity

I

cs

Rated service short-circuit breaking capacity

I

cu

Rated ultimate short-circuit breaking capacity

I

cw

Rated short-time withstand current

I

Δn

Response value of earth-fault release

I

e

Rated operational current

I

g

Response value of earth-fault release

I

i

Response value of non-delayed short-circuit release

I

sc

Transformer initial short-circuit AC current

I

L

Load monitoring response value

I

n

Rated operational current

I

NT

Transformer rated operational current

I

PK

Rated peak withstand current

I

q

Rated conditional short-circuit current

I

r

Overcurrent release set value

I

rm

Response value of non-delayed short-circuit release

I

rmf

Response value of fixed, non-delayed short-circuit release

I

rmv

Response value of short-time delayed short-circuit release

I

sd

Response value of short-time delayed short-circuit release

I

T

Response value of earth-fault release

I

th

Conventional free air thermal current

I

the

Conventional thermal current of enclosed devices

I

u

Rated uninterrupted current

S

NT

Transformer rating

t

g

Delay time when the earth-fault release trips

t

r

Delay time when the overload release responds

t

T

Delay time when the earth-fault release trips

t

v

Time delay of short-circuit release response

U

c

Rated excitation voltage

U

e

Rated operational voltage

U

imp

Rated insulation voltage

U

imp

Rated surge voltage invariability

u

k

Transformer short-circuit voltage

U

s

Rated control voltage

Meaning

Symbol

Conventional free air thermal current

I

th

Conventional thermal current of enclosed devices

I

the

Delay time when the earth-fault release trips

t

g

Delay time when the earth-fault release trips

t

T

Delay time when the overload release responds

t

r

Load monitoring response value

I

L

Overcurrent release set value

I

r

Rated conditional short-circuit current

I

q

Rated control voltage

U

s

Rated excitation voltage

U

c

Rated insulation voltage

U

imp

Rated operational current

I

e

Rated operational current

I

n

Rated operational voltage

U

e

Rated peak withstand current

I

PK

Rated service short-circuit breaking capacity

I

cs

Rated short-circuit breaking capacity

I

cn

Rated short-circuit making capacity

I

cm

Rated short-time withstand current

I

cw

Rated surge voltage invariability

U

imp

Rated ultimate short-circuit breaking capacity

I

cu

Rated uninterrupted current

I

u

Response value of earth-fault release

I

Δn

,

I

g

,

I

T

Response value of fixed, non-delayed short-circuit release

I

rmf

Response value of non-delayed short-circuit release

I

i

Response value of non-delayed short-circuit release

I

rm

Response value of short-time delayed short-circuit release

I

rmv

Response value of short-time delayed short-circuit release

I

sd

Time delay of short-circuit release response

t

v

Transformer initial short-circuit AC current

I

sc

Transformer rated operational current

I

NT

Transformer rating

S

NT

Transformer short-circuit voltage

u

k

Glossary of terms

Symbols used in technical data and formulae
