4
m
4
m
5
m
18
m total
5
m
Master
6004
Slave 1
6005
Slave 2
6005
Slave 5
6005
Slave 4
6005
Slave 3
6005
5
m
4
m
4
m
13
m total
4
m
4
m
5
m
18
m total
5
m
Master
6004
Slave 1
6005
Slave 2
6005
Slave 3
6005
Slave 4
6005
Slave 5
6005
5
m
5
m
4
m
4
m
18
m total
5
m
4
m
4
m
13
m total
63
mm
N L
Power Module
Ceiling 5-25mm
Each power box can have not only one MASTER sensor but also
can extend flexibly up to 5 SLAVE sensors.
6004
POWER BOX
6004
MASTER
SENSOR
30
cm RJ12 Patch Cord
30
cm RJ11 Patch Cord
5
m 1x2 RJ11 Patch Cord
0.2
m 1x2 RJ12 Patch Cord
NOTE: Master x1 – Slave x5
6005
SLAVE
SENSOR
6005
SLAVE
SENSOR
Determine the best location for the sensor. Install the sensor at
least 1m away from fluorescent and HVAC ducts, and at least
1.3
m away from incandescent fixtures and HVAC diffusers.
1.
Determine the best location for the sensor.
2.
Drill a 63mm diameter hole in the ceiling. The thickness of the
ceiling must be between 5mm and 25mm.
3.
Insert the power module into the ceiling first and then fix the
sensor with metal spring as shown.
S
S
PULSE
20
30
10
3 5
1
30
S
PULSE
20
30
10
3 5
1
30
S
PULSE
20
30
10
3 5
1
30
S
TEST
TEST
The sensor has an adjustable “TIME ON” control from 30 seconds
minimum to a maximum of 30 minutes. Light will remain on for
the setting time interval after the last movement is detected.
While there is movement from a heat source in the detecting area
the lighting will remain on and the time will keep resetting.
If time adjustment is set to PULSE, the sensor will enter short pulse
mode. In short pulse mode, the sensor will send a signal to the
device. The signal will be 1 sec ON and 9 sec OFF.
The LUX adjustment controls the light level at which the unit will
switch on the light when movement is sensed. If set to the
maximum position, it will switch during daylight. If set to the
minimum position, it will operate only in total darkness. Ideally it
should be set at dusk or in the light conditions under which the
sensor and lights are expected to operate.
TEST
If LUX adjustment is set to maximum, the sensor will enter TEST
mode. In TEST mode, the light will turn on for 3 sec when PIR is
triggered. Check the detection area and adjust sensor to the
desired angle. Afterwards, it can be switched back to desired time
setting.
The sensor adjustment controls the detection range. If set to the
maximum position, the detection range is about 4m radius. If set to
the minimum position, the detection range is about 0.5m radius.
HEIGHT
RADIUS (M)
2.3
3.5
2.4
4
3.0
5.5
ADJUSTMENTS
l
Ø 8m
360
º
2.4
m
High
Typical maximum layout of master followed by 5 slaves
Master only
Master only
Master only
Master only
