Steel Enclosure Hinged Door
Insulated enclosure Yellow/Red Handle
Accessories
SWITCH DISCONNECTOR STEEL ENCLOSURE
l
Rating Box
(A) Size TP&N/SP&N TP&SWN
20 1
190203NSW1
190204SW1
32 1
190323NSW1
190324SW1
40 1
190403NSW1
190404SW1
63 1
190633NSW1
190634SW1
63 2
190633NSW2
190634SW2
100 2
191003NSW2
191004SW2
125 2
191253NSW2
191254SW2
l
Hinged Door
GENERAL PURPOSE ENCLOSURE
l
Max 3ph
Accepts Rating TP&N 4 Pole
7T1 mccb 140A
7T1-ENC-3N 7T1-ENC-4P
7T2 mccb 250A
7T2-ENC-3N 7T2-ENC-4P
7T3 mccb 550A
7T3-ENC-3N 7T3-ENC-4P
SWITCH DISCONNECTOR INSULATED ENCLOSURE
l
Rating Box Yellow/Red Black/Grey
(A) Size Handle Handle
16 A
15416/11 15416/12
25 A
15425/11 15425/12
32 B
15432/11 15432/12
40 B
15440/11 15440/12
63 C
15463/11 15463/12
80 D
15480/11 15480/12
100 D
154100/11 154100/12
125 E
154125/11 154125/12
l
Gland Fixings are Metric sizes
l
Optional Switched Neutral
15416/11 & 15416/12 have Non-interlocked handles.
ACCESSORIES
l
Description LIST No.
Neutral Link 63amp
19963
125amp
199125
Auxiliary Switch 10amp
19701
Terminal Shrouds
SP 16-63amps (set of 2)
19811
TP 16-63amps (set of 2)
19813
SP 63-125amps (set of 2)
19821
TP 63-125amps (set of 2)
19823
Switched 4th Pole
16A
198164
32A
198324
40A
198404
63A
198634
80A
198804
100A
1981004
125A
1981254
