Standard Range Outgoing Devices & Accessories
MCBs
CAT REF. CURRENT RATING CONTACT SHIELD COLOUR
B6 6A WHITE
B10 10A GREY
B16 16A BLUE
B20 20A YELLOW
B32 32A RED
B40 40A ORANGE
May be used as a direct replacement for rewirable fuses part ref R5, R15, R20
and R30
CARTRIDGE FUSES (Including contact shield)
CAT REF. CURRENT RATING CONTACT SHIELD COLOUR
C5 5A WHITE
C15 15A BLUE
C20 20A YELLOW
C30 30A RED
C35 35A ORANGE
C40 40A ORANGE
C45 45A GREEN
CAT REF. CURRENT RATING
L45 45A
L60 60A
May be used as a direct replacement for rewirable fuses part ref R5, R15, R20
and R30
CARTRIDGE FUSE LINKS
CAT REF. CURRENT RATING CONTACT SHIELD COLOUR
CFL05 5A WHITE
CFL10 10A BLUE
CFL15 15A BLUE
CFL20 20A YELLOW
CFL30 30A RED
CFL35 35A ORANGE
CFL40 40A ORANGE
CFL45 45A GREEN
CARTRIDGE FUSE LINKS
CAT REF. CURRENT RATING
LFL45 45A
LFL60 60A
LFL63 63A
LFL80 80A
LFL100 100A
ACCESSORIES
CAT REF. DESCRIPTION
FWC* Fusewire card 1m 5A, 15A, 30A
M10 Blank shield for unused ways
* Rewirable fuses replaced by Bxx Plug in MCBs or Cxx Cartridge fuses above
B6 B10 B16 B20 B32 B40
C5 C15 C20 C30 C35 C40 C45
CARTRIDGE FUSE LINKS
M10
}
}
}
for use with 108, 145 & 160
type switch fuses
for use with 108 or 108M
for use with 110M
units only
