Domae - quick selector
Select consumer unit
Insulated units
Reference number
No. of ways
Reference number
No. of ways
DOM2CU
2
DOM2MCU
2
DOM4CU
4
DOM4MCU
4
DOM6CU
6
DOM6MCU
6
DOM8CU
8
DOM8MCU
8
DOM12CU
12
DOM12MCU
12
DOM16CU
16
DOM16MCU
16
DOM20CU
20
Select incoming device
Main incoming devices
Reference number
Description
Current rating
DOM63SW
Switch
63A
DOM100SW
Switch
100A
DOM63R30
RCCB
63A 30mA
DOM80R30
RCCB
80A 30mA
DOM100R100
RCCB
100A 100mA
DOM100R100SP
RCCB (TD)
100A 100mA
DOM100R30P
RCCB
100A 30mA
For split load applications select a split load kit
Split load kits [includes cables and RCCB (RCD)]
Reference number
Description
Current rating
DOM63R30KIT2
RCCB and cables
63A 30mA
DOM80R30KIT2
RCCB and cables
80A 30mA
Select consumer unit package
Pre-assembled ready to install consumer unit packages
Reference number Description
Typical application
SHOWER6340D
2 way enclosure + 63A 30mA RCCB and 40A MCB Electric shower supply
SHOWER6345D
2 way enclosure + 63A 30mA RCCB and 45A MCB
Electric shower supply
GARAGE63D
2 way IP55 enclosure + 63A RCD, 6A and 16A MCB Electricity supply to a garage
Select consumer units with switch/RCD’s fitted
Split load kits [includes cables and RCCB (RCD)]
Reference number
Insulated Units
Reference number
Metal units
Total
no.
ways
Description
Switch
only
ways
RCD1
protected
ways
RCD2
protected
ways
DOMR4R4CU DOMR4R4MCU
8 4 + 4 way configurable Domae
CU 100A Sw and 2 63A RCDs
4
4
DOMR6R6CU DOMR6R6MCU
12 6 + 6 way configurable Domae
CU 100A Sw and 2 63A RCDs
6
6
DOMR6R6DCU DOMR6R6DMCU
12
6 + 6 way configurable Domae
CU 100A Sw and 2 80A RCDs
6
6
DOMR8R8DCU
16
8 + 8 way configurable Domae
CU 100A Sw and 2 80A RCDs
8
8
DOMS2R5R5DCU DOMS2R5R5DMCU
12
2 + 5 + 5 way Domae CU
100A Sw and 2 80A RCDs
2
5
5
DOMS2R7R7DCU
16
2 + 7 + 7 way Domae CU
100A Sw and 2 80A RCDs
2
7
7
Metal units
