DECORATIVE WIRING ACCESSORIES
l
RECOMMENDED MOUNTING BOXES FOR DECORATIVE WIRING ACCESSORIES
l
DIMENSION & CLOSE COUPLING DETAILS
Description
PROFILE
A
B
C
D
Flatplate 1 Gang
87.2
mm 87.2mm 2mm 7.45mm
Flatplate 2 Gang
87.2
mm 147.2mm 2mm 7.3mm
Round Edge 1 Gang
86.5
mm 86.5mm 8.2mm 7.1mm
Round Edge 2 Gang
86.5
mm 147mm 8.2mm 7.2mm
Curved Edge 1 Gang
84.4
mm 84.4mm 8mm 6.05mm
Curved Edge 2 Gang
84.4
mm 145.6mm 8mm 6.5mm
Angled Edge 1 Gang
89.7
mm 89.7mm 8.2mm 8.7mm
Angled Edge 2 Gang
89.7
mm 150mm 8.2mm 8.7mm
Decorative Brass 1 Gang
95.7
mm 95.7mm 10.4mm 11.7mm
Decorative Brass 2 Gang
95.7
mm 155mm 10.4mm 11.2mm
A
B
C
D
D
BRITISH STANDARDS
Light Switches
BS EN 60669-1
Intermediate Switches
BS EN 60669-1
Pull Switches
BS EN 60669-1
Fan Isolator
BS EN 60974-3
Toggle Switch
BS EN 60669-1
Standard Dimmer
BS EN 55014, BS EN 60669-1
LowVoltage Dimmer
BS EN 55014, BS EN 60669-1
Touch & Remote Dimmer
BS EN 55014, BS EN 60669-1
BRITISH STANDARDS
Switched Sockets
BS EN 1363
Fuse Connection Units
BS EN 1363
20
A DP Switches
BS EN 60669-1
45
A DP Switches
BS EN 60669-1
Shaver Socket
BS EN61558
Co-Axial Socket
BS 3041
Raised Plate
Flat Plate
Minimum Metal Flush Dry Lining
Description
List no
List no
Gang Box
box Size
box List no box List no
10
AX 1 gang 2 way Switch
VX1020_ _
*
VX3020_ _
1
16
mm
SB623
SB619
10
AX 2 gang 2 way Switch
VX1040_ _
*
VX3040_ _
1
16
mm
SB623
SB619
10
AX 1 gang Intermediate Switch
VX1010_ _
*
VX3030_ _
1
16
mm
SB623
SB619
10
AX 3 gang 2 way Switch
VX1050_ _
-
1
16
mm
SB623
SB619
10
AX 4 gang 2 way Switch
VX1054_ _
*
VX3054_ _
2
16
mm
SB633
SB629
Fan Isolator
VX1013_ _
*
VX3013_ _
1
25
mm
SB655
SB619
1
gang 2 way Toggle Switch
VX1120_ _
*
VX3120_ _
1
25
mm
SB655
SB619
1
gang Intermediate Toggle Switch
VX1130_ _
*
VX3130_ _
1
25
mm
SB655
SB619
2
gang 2 way Toggle Switch
VX1140_ _
*
VX3140_ _
1
25
mm
SB655
SB619
3
gang 2 way Toggle Switch
VX1150_ _
*
VX3150_ _
1
25
mm
SB655
SB619
1
gang 2 way 400W Low Voltage/Mains Dimmer
VX0400LV_ _PU *VX3400LV_ _PU 1
35
mm
SB615
SB619
2
gang 2 way 250W Low voltage/mains Dimmer
VX0252LV_ _PU *VX33252LV_ _PU 1
25
mm
SB655
SB619
3
gang 2 way 250W Low voltage/mains Dimmer
VX0253LV_ _PU *VX3253LV_ _PU 2
25
mm
SB665
SB629
1
gang 2 way 400W Mains Dimmer
VX0400_ _PU *VX3400_ _PU 1
35
mm
SB615
SB619
2
gang 2 way 250W Mains Dimmer
VX0252_ _PU *VX3252_ _PU 1
25
mm
SB655
SB619
3
gang 2 way 250W Mains Dimmer
VX0253_ _PU *VX3253_ _PU 2
25
mm
SB655
SB629
4
gang 2 way 250W Mains Dimmer
VX0254_ _PU *VX3254_ _PU 2
25
mm
SB655
SB629
1
way 500W/500VA Touch Dimmer
VX0500TD_ _
*
VX3005TD_ _
1
35
mm
SB615
SB619
1
way 400W Touch Remote Dimmer
VX0400TRD_ _ *VX3400TRD_ _ 1
35
mm
SB615
SB619
5
A 3 pin socket
VX9905_ _
*
VX3905_ _
1
25
mm
SB655
SB619
13
A 1 gang DP Switched Socket
VX1300_ _ /D *VX3300_ _/D 1
25
mm
SB665
SB629
13
A 2 gang DP Switched Socket
VX1500_ _ /D *VX3500_ _/D 2
25
mm
SB665
SB629
13
A Unswitched Fused Connection Unit
VX1090_ _
*
VX3090_ _
1
25
mm
SB655
SB619
13
A DP Switched Fused Connection Unit
VX1080_ _
*
VX3080_ _
1
25
mm
SB655
SB619
13
A DP Switched Fused Connection Unit with Neon
VX1081_ _
*
VX3081_ _
1
25
mm
SB655
SB619
20
A 1 gang DP Switch with Neon
VX1060_ _
*
VX3060_ _
1
25
mm
SB655
SB619
1
gang 45A Switch
VX9713_ _
*
VX3713_ _
1
47
mm
SB618
SB632
2
gang 45A Switch
VX9703_ _
-
2
47
mm
SB628
SB631
Cooker control unit with Neon
VX9700_ _
*
VX3700_ _
2
47
mm
SB628
SB631
Shaver Socket
VX9800_ _
*
VX3800_ _
2
47
mm
SB628
SB631
Telephone Master Socket
VX9974_ _
*
VX3974_ _
1
25
mm
SB655
SB619
Telephone Secondary Socket
VX9984_ _
*
VX3984_ _
1
25
mm
SB655
SB619
1
gang Co-Axial TV Socket
VX9992_ _
*
VX3992_ _
1
25
mm
SB655
SB619
2
gang Co-Axial TV Socket
VX9993_ _
*
VX3993_ _
1
25
mm
SB655
SB619
1
gang Blanking off plate
VX9991_ _
*
VX3991_ _
1
16
mm
SB623
SB619
2
gang Blanking off plate
VX9996_ _
*
VX3996_ _
2
16
mm
SB633
SB629
1
gang 1 module communication plate
VX9061_ _
*
VX3061_ _
1
16
mm
SB623
SB619
1
gang 2 module communication plate
VX9062_ _
*
VX3062_ _
1
16
mm
SB623
SB619
*
Note: Box size is based on boxes being mounted at least 5mm below plaster depth
