57 / 272
Compact Fluorescent Non Integrated
>
PL-RMASTER PL-R Eco 4 Pin
A
D
B
C
Dim.
A B C D
no.
max. max. max. max.
1 99.7 120 126.6 41
2 121.7 142 148.6 41
The ultimate Saver!
MASTER PL-R Eco is an extremely e cient
compact fluorescent lamp for downlight
applications. It consists of six parallel tubes
with a new innovative ‘twist and lock’ lamp
base, designed for operation with electronic
gear. The MASTER PL-R Eco contains the
original bridge technology invented and
patented by Philips. This guarantees optimum
performance in the application and results in
significantly higher e cacies than with regular
compact fluorescent lamps. On top of that,
MASTER PL-R Eco lamps o er more than
double the service life of a standard compact
fluorescent lamp, thanks to superior lumen
maintenance. The ‘twist and lock’ lamp base
provides easy and safe (dis-)mounting and
sturdy fixation in the luminaire.
Product Benefits
•Up to 50% less energy consumption in
application versus 18 and 26 W PL-C/T
on electromagnetic ballasts for comparable
lighting levels
•Up to 25% less energy consumption in
application versus 18 and 26 W PL-C/T
on electronic drivers for comparable lighting
levels
•Easy lamp (re-)placement and stable fixation
due to new twist and lock lampbase /
holder
•Longer lifetime and less early failures lead
to less hassle and lower maintenance costs
and facilitate the change from spot to group
replacement
•Dimming possible down to 10%
Product Features
•Twist and lock 4-pin lamp base GR14q-1
without starter and capacitor
•Maximum light output reached at approx-
imately 35-40 °C in free-burning base-up
position
•Fluorescent tri-phosphor technology
•Extra long lifetime and less early failures
•Very low light depreciation over lamp life
•Service lifetime of 19,000 hours
Environment
•Most sustainable compact fluorescent
solution for comparable lighting solutions
•Up to 50% reduction of CO
2
emissions
in application and lower light output
depreciation
•Longer service life and lowest mercury
content leads to less environmental waste
•Compliant with all RoHS and WEEE
requirements: very low content of mercury,
lead free and no use of radioactive materials
and hazardous flame retardants
Application
•Designed for general down-lighting in (semi-)
professional indoor applications: o ces,
retail, hospitals, governmental and public
buildings
•Ideal for use in recessed or surface mounted
downlighters, wall units
•Suitable for use in applications where
maintenance costs are high (high ceilings,
di cult to reach):department stores,
supermarkets, warehouses, production halls
and public areas
Warnings and Safety
•Lamp light technical and electrical char-
acteristics are influenced by operating
conditions, i. e. lamp ambient temperature
and operating position as well as applied HF
control gear
•Shorter lamp life when often switching and
not well pre-heated electrodes
MASTER PL-R Eco GR14q-1
Wattage/
Colour Code
Colour
Rendering
Index
Dimma-
ble
Life to 10%
fail Preheat
EL,3h
Life to 50%
fail Preheat
EL,3h
Dim. no.
Packing type/
Packing
configuration
National Order
Code
Ordering
number
8711500...
(R
a
)
(h)
(h)
14W/840
82
yes
19,000
24,000 A 1
1CT / 5X10CC 50
14PLR840ECO
265982
70
yes
17W/830
82
yes
19,000
24,000 A 2
1CT / 5X10CC 50
17PLR830ECO
266019
70
yes
17W/840
82
yes
19,000
24,000 A 2
1CT / 5X10CC 50
17PLR840ECO
266040
70
yes
Philips Lamps and Lighting Electronic Catalogue 2014
57
04
