Lamps & Lighting Electronics Catalogue 2014

143 / 272

> >
MSR Gold™ FastFit
L
C
O
F
C D F L O
max. max. nom. nom. nom.
112 23.2 41 65 3.8
MSR Gold™ FastFit – easy lamp replacement
in seconds
All lamps burn out eventually, but when this
happens with single ended MSR Gold™
FastFit, it is replaced in seconds – thanks
to the specially designed lamp base and
lamp holder. This lamp provides a high
beam intensity of pure, white light for a
truly illuminating performance, while the
gold-plated caps provide superior heat
protection and prevent premature failure. P3
technology allows use in any position and at
higher temperatures, further extending lamp
life
and consistency of high-quality light output.
Also, because the FastFit design is applied to
Philips Halogen lamps, switching between
lamp technologies can be done quickly and
easily.
The Philips MSR Gold™ 1,200 FastFit can be
operated in a lamp wattage range between
800 W and 1,400 W.
•Lamp replacement in just seconds,
exchangeable with halogen lamp
•High beam intensity
•Easy handling, smaller and lighter fixtures
possible
•Boostable light levels
•Enables use at higher temperatures in any
burning position. Longer lifetime, fewer
early failures, consistent performance over
time
•Reduces early lamp or lamp holder failures.
Excellent current transfer
•Pure, white light; colour point close to black
body line
Product Features
•Philips FastFit
•Very short arc
•Compact design
•Flexible power range
•Philips pinch protection
•Innovative gold plated pins
•MSR filling
System
•The Philips MSR Gold™ 1,200 FastFit can be
operated in a lamp wattage range between
800 W and 1,400 W.
Type Rated Lamp
Wattage
Cap-Base Colour
Temperature
Lamp
Luminous
Flux EM
Lamp Current Burning
Position
Packing type/
Packing
configu-
ration
Ordering
number
8718291...
(W) (K) (lm) (A)
MSR Gold™ GOLD 700 PGJX50 6,000 50,000 10.2 any 1CT / 4 4 22119700
Philips Lamps and Lighting Electronic Catalogue 2014 143
08
