Halogen Lamps
>
LV Halogen without ReflectorMASTERCapsule
C D L
max.
max.
nom.
44
12
30
Product Description
•MASTERCapsule with EcoBoost technology:
halogen capsule, 40% more energy saving
than standard capsule
Product Benefits
•Retrofit replacement for standard halogen
capsules
•High energy savings
•Lower replacement costs due to longer
burning hours
•Bright, sparkling white halogen light with
excellent colour rendering
•Supports a green environment
•Excellent beam performance
•Lower cost of ownership compared with
standard halogen capsule
Product Features
•Unique Philips patented EcoBoost single-
ended burner: 40% higher e ciency than
standard products
•GY6.35 lamp base with single-ended
low-pressure burner
•Small size
•Average lifetime up to 4x longer than
standard capsule
•Low-voltage halogen light quality: sparkling,
crisp light
•Dimmable
•No mercury content
•High-performance coating for high e ciency
•Complete range equipped with Philips
EcoBoost technology
Environment
•Excellent environmental choice because of
high energy e ciency and long reliable life
Application
•Replacement for standard capsules in
most professional and semi-professional
applications
•Indoor lighting (e. g. hotels, restaurants,
o ces)
•Enclosed fixtures required for outdoor
applications
MASTERCapsule GY6.35 12V IR Coated
Lamp Wattage Lamp Luminous Flux Rated Lifetime
Packing type/Packing
configuration
National Order Code
Ordering number
8727900...
(W)
(lm)
(h)
20
420
4,000
B
1CT / 5X10F
50
18160
203530
70
30
750
4,000
B
1CT / 5X10F
50
18161
203547
70
45
1,250
4,000
B
1CT / 5X10F
50
18162
203554
70
60
1,700
4,000
B
1CT / 5X10F
50
18163
203561
70
Capsuleline
Product Description
•Single-ended low-voltage halogen capsule
giving crisp white halogen light
Product Benefits
•Low-pressure technology allows use in
luminaires without front glass
Product Features
•Sturdy, low-pressure lamps with UV-Block
glass (IEC 357)
•Gas-filled (
≤
2.5 bar) lamps can be used in lu-
minaires without a front glass in accordance
with IEC 598
•Axial filament for higher light output in
combination with luminaires and a uniform
beam
•Excellent colour rendering
•Universal burning position
Application
•Task lighting and decorative applications in
homes, shops, hotels and restaurants
D
L
C
Dim.
C D L
no.
max. max. nom.
1 33 10 22.2
2 33 10 22.0
3 44 12 30.0
D
L
C
Dim.
C D L
no.
max. max. nom.
4 33 9 22
5 33 9 24
D
L
C
Dim.
C D L
no.
max. max. nom.
6 44 12 30
