MASTER SOX-E BY22d
Wattage Lamp
Luminous
Flux EM
Life to 50%
failures
Burning
Position
Dim. no. Packing type/
Packing
configuration
National Order
Code
Ordering number
8711500...
(W) (lm) (h)
18 1,800 18,000 h110 A+ 1 1SL / 12 12 18SOXE 60023315 yes
26 3,600 18,000 h110 A++ 2 1SL / 12 12 26SOXE 60025715 yes
36 6,100 18,000 p20 A++ 3 1SL / 12 12 36SOXE 60027115 yes
66 10,500 18,000 p20 A++ 4 1SL / 12 12 66SOXE 60029515 yes
91 17,400 18,000 p20 A++ 5 1SL / 12 12 91SOXE 60033215 yes
131 26,200 18,000 p20 A++ 6 1SL / 6 6 131SOXE 73514010 yes
SOX
Product Description
•Low Pressure Sodium lamp
Product Benefits
•High luminous e cacy leads to low energy
consumption
Product Features
•Uniform sodium distribution in the discharge
tube by means of dimples for a more stable
discharge, higher e cacy and better lumen
maintenance and lamp life
•Monochromatic yellow colour with
non-existent colour rendering
Environment
•This product is RoHS compliant
•This product is covered by WEEE
Application
•Road lighting, railway marshalling yards and
crossings, airports, harbours and docks,
quarries, foundries and rolling mills
•Security and orientation lighting
D
C
Dim. C D
no. max. max.
1 311 52
2 425 52
3 528 66
4 775 66
5 1120 66
SOX BY22d
Wattage Lamp
Luminous
Flux EM
Life to 50%
failures
Burning
Position
Dim. no. Packing type/
Packing
configuration
National Order
Code
Ordering
number
8711500...
(W) (lm) (h)
35 4,550 18,000 h110 A+ 1 1SL / 12 12 35SOX 73500315 yes
35 4,550 18,000 h110 A+ 1 1SL / 12 12 35SOXPLUS 19469515 yes
55 7,800 18,000 h110 A++ 2 1SL / 12 12 55SOX 60031815 yes
55 7,800 18,000 h110 A++ 2 1SL / 12 12 55SOXPLUS 19471815 yes
90 13,600 18,000 p20 A++ 3 1SL / 12 12 90SOX 73502715 yes
90 13,600 18,000 p20 A++ 3 1SL / 12 12 90SOXPLUS 19473215 yes
135 22,600 18,000 p20 A++ 4 1SL / 12 12 135SOX 73504115 yes
135 22,600 18,000 p20 A++ 4 1SL / 12 12 135SOXPLUS 19475615 yes
180 32,000 18,000 p20 A++ 5 1SL / 6 6 180SOX 73516410 yes
