67 / 221
67
Technical data pages 207 to 210
Material: POLYAMIDE PA6.6
self-extinguishing class V2 (UL 94)
Temperature range:
–20°C to +90°C (continuous)
Sealing ring: NEOPRENE
®
50 sh A
Protection: IP 68
Colour: RAL 7035 light grey,
RAL 9005 black
File no. E220310
File no. E220310
BSP thread
ISO 228/1
standard
Ref.
Grey
P
Light
Fixing
Hole
Ø
(mm)
Ø A
mini-max
(mm)
B
Spanner
(mm)
C
(mm)
L
min-max
(mm)
Quantity
1900.14
G1/4’’
13,5
3- 6,5
15
8
18-22
100
1900.38
G3/8’’
17,0
4- 8
19
8
22-26
100
1900.12
G1/2’’
21,5
7-12
24
10
24-29
100
1900.34
G3/4’’
27,0
13-18
33
12
30-35
50
Add to Ref: N for Black
1900DP
CABLE GLANDS
Polyamide PA6.6
Metric thread M 1.5 pitch
CEI EN 60423 CEI EN 50262
standard, factory fitted with Polyethylene foam discs
Pg thread
DIN 40 430
Ref.
P
Fixing
Hole
Ø
(mm)
Ø A
mini-max
(mm)
B
Spanner
(mm)
C
(mm)
L
min-max
(mm)
Quantity
Box/Bag
1900DP.M12
M12x1,5
12,2
3,5- 7
15
8
18-22
100/10
1900DP.M16
M16x1,5
16,2
5 -10
19
8
22-27
100/10
1900DP.M20
M20x1,5
20,5
7 -13
25
9
24-30
50/10
1900DP.M25
M25x1,5
25,4
10 -17
30
10
28-39
30/10
1900DP.M32
M32x1,5
32,5
13 -21
36
10
33-44
20/10
1900DP.M40
M40x1,5
40,5
19 -28
46
10
36-45
10/5
1900DP.M50
M50x1,5
50,5
27 -35
55
12
43-52
10/5
1900DP.M63
M63x1,5
64,0
34 -45
66
12
45-55
5/5
Ref.
P
Fixing
Hole
Ø
(mm)
Ø A
mini-max
(mm)
B
Spanner
(mm)
C
(mm)
L
min-max
(mm)
Quantity
Box/Bag
1900DP.07
Pg 7
12,7
3,5- 7
15
8
18-22
100/10
1900DP.09
Pg 9
15,5
5 - 8
19
8
22-26
100/10
1900DP.11
Pg11
18,8
5 -10
22
8
23-28
100/10
1900DP.13
Pg13,5
20,5
7 -12
24
9
24-29
50/10
1900DP.16
Pg16
22,6
10 -14
27
10
26-31
30/10
1900DP.21
Pg21
28,5
13 -18
33
12
30-35
20/10
1900DP.29
Pg29
37,2
18 -25
42
12
33-39
20/10
1900DP.36
Pg36
47,2
20 -32
53
14
42-49
10/5
1900DP.42
Pg42
54,2
28 -38
60
14
42-50
5/5
1900DP.48
Pg48
60,0
37 -45
66
15
45-55
5/5
Material: POLYAMIDE PA6.6
self-extinguishing class V2 (UL 94)
Temperature range:
–20°C to +90°C (continuous)
Sealing ring: NEOPRENE
®
50 sh A
Protection: IP 68
Colour: RAL 7035 light grey
Discs: 2 mm thick Polyethylene
foam
1900
