164 / 221
164
Max
cutting Ø
mm
Weight kg
(with battery)
Battery
length
height
width
D i m e n s i o n s m m
50
405
398
83
18.0 V 4.0 Ah
5,8
Next generation of 18.0 V
cordless hydraulic cutting
tool specifically designed
to cut Copper, Alumini-
um, Aluminum-Steel ca-
bles (ACSR) having a max
overall diameter of 50 mm.
The blades are manufac-
tured from high strength
special Steel, heat
treated to ensure a
long service life.
New Li-Ion 18 V 4
Ah batteries offer a
higher capacity than
14.4 V 3 Ah, while great-
er cutting speed and cutting force
result from a revitalised hydraulic
system with double speed action.
18.0 V CORDLESS HYDRAULIC CUTTING TOOL
general features
The battery is equipped
with LED indicators to show
the remaining battery life
at any time by pressing the
adjacent button.
The head can rotate
through 90 degrees, to en-
able the operator to work in the
most comfortable position, and can
easily be opened to allow cutting of
running cables.
Fitted with a maximum hydraulic
pressure valve.
Designed with improved balance,
B-TC500YE is easily manageable
during the cutting process and, by
the use of bi-component plastics,
has a shell with high resistance to
wear and damage.
Not suitable for cutting stay wire, Steel rope or
earthing rod.
Next generation of 18.0 V cordless
hydraulic cutting tool Specifically de-
signed cut Copper, Aldrey, Alumin-
ium, Aluminium-Steel cables
and Steel ropes, Aluminium
and Steel rods having a max
overall diameter of 55 mm.
The blades are manufac-
tured from high strength spe-
cial Steel, heat treated to ensure
a long service life.
New Li-Ion 18 V 4 Ah batteries of-
fer a higher capacity than 14.4 V 3
Ah, while greater cutting speed and
18.0 V CORDLESS HYDRAULIC CUTTING TOOL
general features
cutting force result
from a revitalised
hydraulic system
with double speed action.
The battery is equipped with LED
indicators to show the remaining
battery life at any time by pressing
the adjacent button.
The head can rotate through 320
degrees, to enable the operator to
work in the most comfortable posi-
tion, and can easily be opened to
allow cutting of running cables.
Fitted with a maximum hydraulic
pressure valve.
Designed with improved balance,
B-TC550E is easily manageable dur-
ing the cutting process and, by the
use of bi-component plastics, has a
shell with high resistance to wear
and damage.
The tool is supplied as
:
•
Basic tool with battery and
shoulder strap
•
Spare battery
•
Battery charger
•
USB cable
•
Plastic carrying case suitable for
storing the tool and accessories
S T O R A G E
Type
Dimensions mm Weight
kg
Supplied
with the tool
Purchase
separately
VALP40
520x432x126
2,6
�
—
Max
cutting Ø
mm
Weight kg
(with battery)
Battery
length
height
width
D i m e n s i o n s m m
55
441
424
87
18.0 V 4.0 Ah
8,9
S T O R A G E
Type
Dimensions mm Weight
kg
Supplied
with the tool
Purchase
separately
VALP40
520x432x126
2,6
�
—
The tool is supplied as
:
•
Basic tool with battery
and shoulder strap
•
Spare battery
•
Battery charger
•
USB cable
•
Plastic carrying case suitable for
storing the tool and accessories
18V Li-Ion
B
A
T
T
E
R
Y
N
E
W
Rubber grip inserts, low noise and
minimal vibration aid operator com-
fort while additional convenience
and safety are provided by LED
lighting of the working area.
Operating temperature:
-15 to +50 ° C
New
Rubber grip inserts, low noise and
minimal vibration aid operator com-
fort while additional convenience
and safety are provided by LED
lighting of the working area.
For cutting capacity data see
page 144.
Operating temperature:
-15 to +50 ° C
OVERHEAD LINE APPLICATION
B-TC550E
New
18V Li-Ion
B
A
T
T
E
R
Y
N
E
W
OVERHEAD LINE APPLICATION
B-TC500YE
