147 / 221
147
RHTD 3241 RHTD 1724 RHTD 410T
66
40,5
83
36
25
41
208
150,5
231
75,5
54
76
16
7,5
46
A
B
C
D
E
D I M E N S I O N S m m :
A
C
B
E
D
SPECIAL TOOLS
general features
Nut splitting
heads
RHTD
Hydraulic nut splitting head
complete with automatic quick
coupler. For operating the head
must be joined to a hydraulic pump
developing a pressure of 700 bar
(see page 170-174).
VAL P4
Supplied in a robust
plastic case.
Suitable for splitting nuts
mm
Max operating
pressure
bar
Weight
kg
16 (M10) ÷ 27 (M18)
700
1,76
RHTD 1724
Suitable for splitting nuts
mm
Max operating
pressure
bar
Weight
kg
27 (M18) ÷ 41 (M27)
700
4,6
RHTD 3241
Suitable for splitting square and hexagonal nuts
or fastening bushes mm
Max operating
pressure
bar
Weight
kg
27 (M18) ÷ 41 (M27)
700
4,9
RHTD 410T
*Supplied with the head
S T O R A G E
Type
Dimensions mm
Weight
kg
VAL P4*
315x300x95
0,93
A
B
C
E
D
B-TD270E
18.0 V battery operated hydraulic tool suita-
ble for splitting fastening bushes, hexagonal
and square nuts as per RHTD 1724.
B-TD410TE
18.0 V battery operated hydraulic tool suit-
Suitable for splitting nuts
mm
Dimensions
mm
Weight
kg
16 (M10) ÷ 27 (M18)
1.292,5 x 83 x 350
5,5
B-TD270E
Suitable for splitting square and hexagonal nuts
or fastening bushes mm
Dimensions
mm
Weight
kg
27 (M18) ÷ 41 (M27)
1.360 x 83 x 350
8,8
B-TD410TE
New
New
able for splitting fastening bushes, hexagonal
and square nuts as per RHTD 410T.
APPLICATION RANGE TOOLS TYPE RHTD AND B-TD
TOOL TYPE
HEXAGONAL NUTS
SQUARE NUTS
RHTD 1724
B-TD270E
16
M 10
17
M 10
17
M 10
19
M 12
18
M 12
22
M 14
19
M 12
24
M 16
21
M 14
27
M 18
22
M 14
24
M 16
27
M 18
27
M 18
RHTD 3241
RHTD 410T
B-TD410TE
27
M 18
27
M 18
30
M 20
30
M 20
32
M 22
32
M 22
34
M 22
34
M 24
36
M 24
36
M 27
41
M 27
