48 Downlights
High performance commercial LED downlight
• Market leading performance at up to 92 lpcW
• 2x26W CFL direct replacement
• Over 50% energy saving
• CRI 90, suitable for retail applications
• Zero maintenance, no need to relamp
• Shallow recess depth - standard ceiling cutout size
• Pre-wired with GST plug for quick and easy installation (standard fitting only)
CODE DESCRIPTION WATT LUMENS
JC5420 Coral LED™ non-dimmable 24W 2200
JC5420/1-10V Coral LED™ 1-10V dimmable 24W 2200
JC5420DALI Coral LED™ DALI dimmable 24W 2200
JC5420DSI Coral LED™ DSI dimmable 24W 2200
JC5420EM Coral LED™ non-dimmable emergency 24W 2200
JC5420EM/1-10V Coral LED™ 1-10V dimmable emergency 24W 2200
JC5420EMDALI Coral LED™ DALI dimmable emergency 24W 2200
JC5420EMDSI Coral LED™ DSI dimmable emergency 24W 2200
JC5410 Coral LED™ concealer ring white - -
*Requires online registration
CONSTRUCTION
Body – Die-cast aluminium
Reflector & rim - Aluminium
FINISH
See rim options on page 50
CLASSIFICATION
Class 1
Class 2 (dimmable only)
IP20 | IP65 with additional rim | 240V
LED
4000K | CRI: Ra (90)
4000K
CUTOUT SIZES
Ø212mm
98mm
Ø222mm
384mm
287.5mm
200mm
98mm
Ø212mm
Ø260mm
JC5410
5 year
Extended warranty*
Dimmable
Options
Rim options
See page 50
Emergency
Versions available
STANDARD &
STANDARD EMERG.
DIMMABLE &
DIM EMERG.
Coral LED 24W
™
JC5420
Rim not included -
Shown with JC5052N
