Fire-rated downlights

No tools required

LevLink™ uses push-fit termination which, unlike traditional screw-fit terminals, requires no tools

for installation. Simply align the L,E,N wires with the respective terminals and the PCB reconfigures

without the need to overlay separate wires into single terminal points. This dramatically reduces

time and improves ease of installation.

WIDE ACCESS & LARGE

TERMINAL BUTTONS

LevLink™ allows for wide

access to the terminals,

as well as large buttons.

ACCEPTS SOLID &

STRANDED CABLE

LevLink™ has been designed to

accommodate both solid and

stranded cable types.

Ultra fast push-fit termination

9 Way connector & T- splitter

First fix

LevLink™ has been designed to allow for first fix installation. This allows testing of the circuit

to be carried out prior to the installation of the fitting, minimising the risk of damage.

The secure cable restraint ensures complete peace of mind during installation.

TRADITIONAL SCREW FIT

CONNECTOR

LEVLINK™ PUSH FIT

CONNECTOR

LevLink

™

SIGNIFICANTLY FASTER

SWITCH LIVE WIRING

The LevLink™ 9-way connector used in conjunction with the T-splitter

dramatically reduces the speed of first fix switch live wiring. In addition,

this also enables installers to replace existing ceiling rose wiring.

The ultra fast tool-less

wiring system
