Highbay & Lowbay
Toughbay
Circular
™
Ideal for open areas to provide wide even light distribution
•
Direct HID metal halide replacement
•
Wide 105° beam angle (without reflector)
•
Focused 60° beam angle (with reflector)
•
IP65 as standard
•
1-10V dimmable as standard
•
Ultra efficient, over 100 LpcW
Toughbay
Linear
™
Ideal for aisle & racking areas
CIBSE Guidelines
for industrial applications
CIBSE (Chartered Institution of Building Services Engineers) guidelines for industrial applications.
Measured at 0.75m from floor level.
•
Direct HID and fluorescent replacement
•
IP65 as standard
•
1-10V dimmable as standard
•
Suitable for high racking applications
•
Provides required light distribution for aisles
•
Adjustable mounting points for easy installation
Aisle/racking
Mounted at 10m
150 - 200 lux
Open Areas
Mounted at 8m
300 lux
Retail/Showrooms
Mounted at 8m
500-700 lux
Production Areas
Mounted at 6m
500 lux
6m/Ø7m
10m/Ø11.5m
8m/Ø20m
12m/Ø13.9m
4m/Ø4.6m
Indicates diameter of the beam at distance
Indicates distance measured from fitting
8m/Ø9.2m
6m/Ø15m
116 lux
6m/Ø15m
260 lux
4m/Ø10m
100W
124 lux
220 lux
180W
6m/Ø15m
4m/Ø10m
150 lux
260 lux
230W
105° beam angle
(Without reflector)
8m/Ø9.2m
6m/Ø7m
284 lux
504 lux
180W
100W
150 lux
214 lux
334 lux
230W
60° beam angle
(With reflector)
110° beam angle
208 lux
469 lux
3m/Ø8.6m
6m/Ø15m
4m/Ø11.5m
8m/Ø20m
2m/Ø5.6m
135 lux
100 lux
280 lux
75W
223 lux
150 lux
210W
4m/Ø11.5m
5m/Ø14.2m
203 lux
130 lux
150W
