All light duty tray lengths up to and including LD225T will be supplied with an inwards form on
one end (to eliminate the need for couplers). LD300/T and above require the use
of couplers. A range of gauges are available on request.
Straight Coupler
Tray width less 58mm
Fish Plate
225-900
Cranked Coupler Reducer
SR
Total length 250mm.
Please state sizes required.
Light Duty Cable Tray (in accordance with BS 61537:2007)
Flat 90° Bend
50-900FB90
50 75 100 150 225 300 450 600 750 900
X
Y
Z
Size
Earth Link
Ref.CES (Plain Copper)
Ref.TCES (Tinned Copper)
Ref.EBS100 (M6 Braid)
Length 161mm.
Sold in pairs.
Sold in pairs.
Bolts & Nuts
Ref.M6X12
Order separately.
Z
X
Y
SIZE
LIGHT DUTY CABLE TRAY SYSTEMS
Swaged joint
750 - 900 ONLY
If you require 50 - 600 in please refer to the Cable Tray section on page 54
Available across this size range Available across this size range
If you require 50 - 600 in please refer to the Cable Tray section on page 53
LD50T
LD75T
LD100T
LD150T
LD225T
LD300T
LD450T
LD600T
LD750T
LD900T
Ref.
Tray Width
mm
50
75
100
150
225
300
450
600
750
900
750 - 900
ONLY
Available across this size range
126 151 175 225 375 450 600 750 900 1058
166 191 215 265 415 490 640 790 940 1098
107 107 107 107 211 211 211 211 211 211
