Electronic Sytems Protection
Unity PF Designed Systems
EMEX Power - Single Phase 220-240 V 50/60 Hz
Commercial Rating
ICEL Rating
1 Hour Duration 1.5 Hour Duration 2 Hour Duration 3 Hour Duration
VA
Watts
VA
Watts
Emex Power
Part No.
Emex Power
Part No.
Emex Power
Part No.
Emex Power
Part No.
1500
1500
1250
1250
ELD8110.015
ELD8151.015
ELD8210.015
ELD8310.015
3000
3000
2500
2500
ELD8110.030
ELD8151.030
ELD8210.030
ELD8310.030
4500
4500
3750
3750
ELD8110.045
ELD8151.045
ELD8210.045
ELD8310.045
6000
6000
5000
5000
ELD8110.060
ELD8151.060
ELD8210.060
ELD8310.060
7500
7500
6250
6250
ELD8110.075
ELD8151.075
ELD8210.075
ELD8310.075
9000
9000
7500
7500
ELD8110.090
ELD8151.090
ELD8210.090
ELD8310.090
10500
10500
8750
8750
ELD8110.105
ELD8151.105
ELD8210.105
ELD8310.105
12000
12000
10000
10000
ELD8110.120
ELD8151.120
ELD8210.120
ELD8310.120
13500
13500
11250
11250
ELD8110.135
ELD8151.135
ELD8210.135
ELD8310.135
15000
15000
12500
12500
ELD8110.150
ELD8151.150
ELD8210.150
ELD8310.150
16500
16500
13750
13750
ELD8110.165
ELD8151.165
ELD8210.165
ELD8310.165
18000
18000
15000
15000
ELD8110.180
ELD8151.180
ELD8210.180
ELD8310.180
19500
19500
16250
16250
ELD8110.195
ELD8151.195
ELD8210.195
ELD8310.195
21000
21000
17500
17500
ELD8110.210
ELD8151.210
ELD8210.210
ELD8310.210
22500
22500
18750
18750
ELD8110.225
ELD8151.225
ELD8210.225
ELD8310.225
24000
24000
20000
20000
ELD8110.240
ELD8151.240
ELD8210.240
ELD8310.240
EMEX Power - Three Phase 220-240 V, 380-415 V 50/60 Hz (adjustable)
Commercial Rating
ICEL Rating
1 Hour Duration 1.5 Hour Duration 2 Hour Duration 3 Hour Duration
VA
Watts
VA
Watts
Emex Power
Part No.
Emex Power
Part No.
Emex Power
Part No.
Emex Power
Part No.
4500
4500
3750
3750
ELD8130.045
ELD8153.045
ELD8230.045
ELD8330.045
9000
9000
7500
7500
ELD8130.090
ELD8153.090
ELD8230.090
ELD8330.090
13500
13500
11250
11250
ELD8130.135
ELD8153.135
ELD8230.135
ELD8330.135
18000
18000
15000
15000
ELD8130.180
ELD8153.180
ELD8230.180
ELD8330.180
22500
22500
18750
18750
ELD8130.225
ELD8153.225
ELD8230.225
ELD8330.225
27000
27000
22500
22500
ELD8130.270
ELD8153.270
ELD8230.270
ELD8330.270
31500
31500
26250
26250
ELD8130.315
ELD8153.315
ELD8230.315
ELD8330.315
36000
36000
30000
30000
ELD8130.360
ELD8153.360
ELD8230.360
ELD8330.360
40500
40500
33750
33750
ELD8130.405
ELD8153.405
ELD8230.405
ELD8330.405
45000
45000
37500
37500
ELD8130.450
ELD8153.450
ELD8230.450
ELD8330.450
49500
49500
41250
41250
ELD8130.495
ELD8153.495
ELD8230.495
ELD8330.495
54000
54000
45000
45000
ELD8130.540
ELD8153.540
ELD8230.540
ELD8330.540
58500
58500
48750
48750
ELD8130.585
ELD8153.585
ELD8230.585
ELD8330.585
63000
63000
52500
52500
ELD8130.630
ELD8153.630
ELD8230.630
ELD8330.630
67500
67500
56250
56250
ELD8130.675
ELD8153.675
ELD8230.675
ELD8330.675
72000
72000
60000
60000
ELD8130.720
ELD8153.720
ELD8230.720
ELD8330.720
76500
76500
63750
63750
ELD8130.765
ELD8153.765
ELD8230.765
ELD8330.765
81000
81000
67500
67500
ELD8130.810
ELD8153.810
ELD8230.810
ELD8330.810
Suffix Description
/60
60Hz system - USA Bat only
/U
USA origin Batteries
/N
Nicad Cells
/TS
Touch screen
/XB
Excluding Batteries (Systems are Not Kite marked unless batteries are
supplied by TNB)
XB code will generally be used to split order to delay battery delivery
and will not show on documentation or product in this instance.
When used to supply system without battery the Code will need to
show on documentation.
/NL
Dutch version
/M
Mexico origin Batteries
Example
ELD9110.015/N/TS
ELD9110.015/60/TS
ELD9110.015/NL/XB
ELD9110.015/NL/XB
Part Code Key:
ELD
A B C D . E F G
A
= Power factor - 9 for 0.85PF or 8 for 1.0 Unity PF
B (C)
= Duration - 1 for 1hr 15 for 1.5hr 2 for 2hr and 3 for 3hr
C (D)
= Phase - 1 for Single and 3 for 3 Phase
EFG
= KVA (multiplied by 0.1)
Example
ELD9110.015 = 0.85PF, 1hr, 1 Phase @ 1.5KVA
ELD9151.015 = 0.85PF, 1.5hr, 1 Phase @ 1.5KVA
Order codes
