Central power supplies
Our Central Power Supply Systems division offers a choice of reliable and high quality products
which are designed to meet the relevant standards and specifications for both AC/AC and AC/DC
applications. The ‘EMEX Power’ and ‘EMEX TS’ static inverters, ‘EMEX 110’ AC/DC and ‘Compact Power’
product ranges are manufactured in our Leeds facility, supported by an experienced engineering, sales,
and commissioning team.
Static inverters in this range are true passive stand-by emergency lighting units, designed and built to
exceed current emergency lighting standards and technical requirements, something with which most
UPS based central power products do not comply.
EMEX Power, EMEX TS static inverters and EMEX Mini power systems offer a low maintenance and extremely
reliable central power supply solution with low running costs and a high degree of functionality to serve individual
customer needs.
The ‘EMEX110’ range is available where the user preference is for
an AC/DC system powering slave luminaires fitted with compatible
inverter modules. The 110 V range is suitable for medium to large
premises, including schools, supermarkets and other commercial or
local authority properties.
Structurally, the type enjoys the modular design and all the standard
features of the EMEX range.
Modular design, which makes maintenance or repair a simple task
Manufactured in the UK
Normal mains luminaires with electronic starters/high frequency ballasts
may be driven by the system (glow wire starters cannot be used in
accordance with BS EN 60598.2.22)
Ideal for task lighting projects where normal (high) lighting levels
are required to minimise business disruption
High efficiency: Low running cost
- This AC/AC type of system has been designed for an inherently long
service life with associated significant cost benefits over alternative
emergency lighting solutions
Cost conservancy and design
- Ventilation fan life is maximised, as they will only operate when
required, during ‘battery charge’ or ‘inverter active’ cycles
- Battery life conserved by a temperature compensated constant voltage
charger circuit in conjunction with passive stand-by inverter operation
Functional features include sub-circuit monitoring, final exit input, MCB
monitoring, M/NM operation (user selectable), fire alarm input and two
volt-free common alarm outputs
MCB protection devices are used throughout the equipment,
eliminating the need for fuse spares
Digital display for battery and output metering V & I
Fully compliant with EN 50171 and ICEL1009
EMEX TS includes integral touch-screen with EMEX Test capability
EMEX – AC/AC Static inverter range: 220-230 V 50/60Hz
EMEX110 – AC/DC Central Power Supply Systems: 110 V
Emergi-Lite EMEX AC/AC CPS systems are now kitemark
approved to EN 50171 (Kitemark reference KM 542294).
