Steel trunking systems
186 |
Steel trunking solutions
Description
System 130
System 170
Base unit 2 metre
351215
351216
Cover 1 metre
351210
351210
Cover 1.5 metre
351230
351230
Dividing fillet*
351189
351189
External tolerance sleeve
351075
351076
External joint cover
351105
351106
End cap
351045
351046
Internal bend base
351275
351276
External bend base
351305
351306
External bend cover
351240
351240
Universal int/ext bend
351175
351176
Flat angle base up/down
351335
351336
Flat angle cover
351260
351260
Flat tee base – up/down
351395
351396
Internal coupling/bonding set
351525
351526
Universal multi-purpose clip
351319
351319
Our compact Steel trunking systems incorporate stylish clean
lines with a functionality that provides greater mechanical
strength combined with first class fire performance and excellent
screening capability.
•
Ease of installation - our base unit has two standard mounting holes
of 6.5mm every 500mm
•
Multiple earthing possibilities in the trunking, at the multi-purpose clip
and with the coupler set
•
Base systems held by internal coupler sets with scraping cams
•
Friction fit covers
•
Simple to cut system - empty base with no rail to cut through
•
Wide range of fittings and accessories
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
12
11
4
1
6
* Please note 2 Universal multi-purpose clips (see page 189) are needed per length of trunking,
and 2 Universal multi-purpose clips are needed to hold each dividing fillet in place.
