Sollysta Wiring Accessories

10 / 68

WMPS11
WMPS12W
WMDS1
WMDR1/400R
• Quick press for on/off.
• Rotary dimming control.
• 1 or 2 way switching.
• Supplied with M3.5 x 30mm
long fixing screws.
• Suitable for resistive loads e.g.
incandescent loads.
• Suitable for mains halogen
lamps without the need for
derating.
• Not suitable for fluorescent,
LED or inductive loads.
• Complies with
BS EN 60669-2-1 (excluding
clause 26 EMC requirements).
• Also available in our grid range
see page 7.38
10 Sollysta Wiring Accessories Catalogue
Wall Switches & Dimmers
Wall Switches Ref.
10AX 1 Gang 1 Way Wall Switch WMPS11
10AX 1 Gang 1 Way Wall Switch Printed 'Fan' WMPS11/FAN
10AX 1 Gang 2 Way Wall Switch WMPS12
10AX 2 Gang 2 Way Wall Switch WMPS22
10AX 3 Gang 2 Way Wall Switch WMPS32
10AX 4 Gang 2 Way Wall Switch WMPS42
10AX 6 Gang 2 Way Wall Switch WMPS62
10AX 1 Gang 2 Way Wall Switch Wide Rocker WMPS12W
10AX 2 Gang 2 Way Wall Switch Wide Rocker WMPS22W
Intermediate Switches
Intermediate Switch WMPS16
Intermediate Switch Wide Rocker WMPS16W
Push Switches
Push Switch (Retractive) WMPS12R
Push Switch with Bell Symbol WMPS12RB
Push Switch Wide Rocker WMPS12RW
• Unique patented loop
terminal allows neutral
looping at the switch.
• Complies with
BS EN 60669-1, a.c only.
• 'X' rated - No need to
derate for fluorescent loads.
• Two way switches can be
wired either 1 way or 2 way.
• Clear terminal markings:
1-way L1
2-way L2
• Capacity of each terminal
2 x 4.0mm2 conductors.
• For mounting boxes see
selection chart on page
• For multigang switches use of
a 25mm mounting box will
provide increased wiring
space.
• Supplied with M3.5 x 20mm
long fixing screws.
Ref.
1 Gang Dimmer 400W WMDS1
2 Gang Dimmer 250W WMDS2
3 Gang Dimmer 250W WMDS3
4 Gang Dimmer 250W WMDS4
Resistive Load for LED Applications WMRESLOAD
Ref.
1 Gang Dimmer 400W WMDR1/400R
2 Gang Dimmer 250W WMDR2/250R
Resistive Load for LED Applications WMRESLOAD
• Stylish flush buttons give easy
press action.
• Quick press for on/off.
• Hold button down to dim or
brighten light level.
• Leading edge.
• Soft start feature prolongs
lamp life.
• Suitable for dimming mains
and dimmable transformer
extra low voltage lamps.
• Complies with
BS EN 60669-2-1 (including
BS EN 55015).
• Automatic switch off in event
of transformer instability
protects the dimmer and the
transformer.
• Supplied with M3.5 x 30mm
long fixing screws.
Wall Switches
Switch Dimmers
Rotary Push Button Dimmers
