365 / 759
ESU2211WHI
25
1 GANG 25MM
ONE ENTRY (SIDE)
ESU2512WHI
25
1 GANG 25MM
TWO ENTRIES
(TOP & BOTTOM)
ESU2223WHI
10
2 GANG 25MM
THREE ENTRIES
(TOP & BOTH SIDES)
ESU2523WHI
10
2 GANG 25MM
THREE ENTRIES
(TOP & BOTTOM)
ESU2713WHI
10
1 GANG 32MM
THREE ENTRIES
(TOP & BOTTOM)
ESU2721WHI
10
2 GANG 32MM
ONE ENTRY
CENTRE (TOP)
ESU4423WHI
5
2 GANG 41MM
THREE ENTRIES
(TOP & BOTH SIDES)
Ega Round and Square Corner boxes
are for use in conjunction with mini
trunking adaptors,
reference:
YEA – straight entry and
YSA – side entry.
Material:
PVCu
Dimensions:
1 gang: 86 x 86mm
2 gang: 86 x 146mm
Fixing Centres:
1 gang: 60.3mm
2 gang: 120.6mm
BS 4662 and BS 5733
where applicable.
ESU32125WHI
10
1 GANG TO FIT 25 X 16MM
TRUNKING. TWO ENTRIES
ESU32140WHI
10
1 GANG TO FIT 40 X 16MM
TRUNKING. TWO ENTRIES
ESU32225WHI
10
2 GANG TO FIT 25 X 16MM
TRUNKING. TWO ENTRIES
ESU32240WHI
10
2 GANG TO FIT 40 X 16MM
TRUNKING. TWO ENTRIES
Side mounting boxes do not require
adaptors and can be used with
25mm x 16mm and
40 x 16mm mini trunking.
Material:
PVCu
Dimensions:
1 gang: 86* x 86mm
2 gang: 86* x 146mm
* excluding plinth
Fixing Centres:
1 gang: 60.3mm
2 gang: 120.6mm
BS 4662 and BS 5733
where applicable.
Round
Corner
Accessory
Boxes
Square
Corner
Accessory
Boxes
ESU3511WHI
ESU3523WHI
ESU2211WHI
ESU2512WHI
ESU2523WHI
ESU2713WHI
ESU2721WHI
ESU4423WHI
ESU32140WHI
ESU32225WHI
Egaline
Wall Box
Assemblies
ESUUSB17WHI
5
1 GANG
38MM DEPTH
FOUR ENTRIES
(NON UK)
ESUUSB19WHI
5
1 GANG
45MM DEPTH
FOUR ENTRIES
(NON UK)
ESUUSB22WHI
5
1 GANG
51MM DEPTH
FOUR ENTRIES
(NON UK)
ESUUSB53WHI
5
2 GANG
DEEP BOX
FOUR ENTRIES
(NON UK)
Egaline Wall Box assemblies are for
use in conjunction with Mini Trunking
Spout adaptors reference:
YEA – straight entry and YSA-side
entry.
Material:
PVCu
Dimensions:
1 gang: 124 x 79mm
ESUUSB17WHI
ESUUSB19WHI
ESUUSB22WHI
ESUUSB53WHI
ESU231WHI
25
1 GANG 25MM
ONE ENTRY
CENTRE (TOP )
ESU2311WHI
25
1 GANG 25MM
ONE ENTRY (SIDE)
ESU2323WHI
10
2 GANG 25MM
THREE ENTRIES
(TOP & BOTH SIDES)
ESU3511WHI
25
1 GANG 32MM
ONE ENTRY
CENTRE (TOP)
ESU3523WHI
10
2 GANG 32MM
THREE ENTRIES.
(TOP, LEFT & RIGHT SIDE)
SURFACE
SIDE MOUNTING
SURFACE
FOR AMERICAN
ACCESSORIES
ESU2323WHI
ESU2311WHI
ESU231WHI
SURFACE
SURFACE
MK Electric Catalogue
365
Technical Hotline
+44 (0)1268 563720
CABLE MANAGEMENT
CONDUIT
AND MINI
Ega Mini
®
