FILTERED
FLUSH
13 AMP
K6300WHI 1
1 GANG DP
30mA RATED TRIPPING
CURRENT ACTIVE
CONTROL CIRCUIT
K6303WHI 1
1 GANG DP
30mA RATED TRIPPING
CURRENT PASSIVE
CONTROL CIRCUIT
MOUNTING BOXES
FLUSH
886ZIC – 35mm deep
SURFACE
K2140WHI – 30mm deep
EARTH PIN OPERATED SHUTTER
These a.c. and pulsating d.c. fault current sensitive products
have up to 15mm thick frontplates and are suitable for boxes
with 30mm min. depth and supply voltages of 240V 50Hz.
A 25mm deep box (862ZIC) can be used but conduit entry is
restricted.
Refer to Sentrysocket section, page 288, for more information
on active and passive control circuits.
DIMENSIONS
86 x 146mm
FIXING CENTRES
120.6mm
BS 7288:1990
All units are a.c. and pulsating d.c. fault current
sensitive devices.
Maximum total load 13A
K1816WHI 1
2 GANG DP
SPIKE
K1826WHI 1
2 GANG DP
SPIKE AND RFI
K1800WHI 5
REPLACEMENT FILTER
CASSETTE
MOUNTING BOXES
FLUSH
886ZIC
SURFACE
K2172WHI
K1816
Provides filtering to reduce voltage spikes only.
K1826
Provides two way filtering to reduce voltage spikes and radio
frequency interference on the mains. Protected by thermal
cut-out.
BS 5733:2010
K6300WHI K1816WHI
RCD PROTECTED
FLUSH
13 AMP
K6231WHI 1
2 GANG SP
30mA RATED TRIPPING
CURRENT
ACTIVE CONTROL CIRCUIT
K6233WHI 1
2 GANG SP
30mA RATED TRIPPING
CURRENT
PASSIVE CONTROL CIRCUIT
MOUNTING BOXES
FLUSH
886ZIC – 35mm deep
SURFACE
K2140WHI – 30mm deep
EARTH PIN OPERATED SHUTTER
These a.c. and pulsating d.c. fault current sensitive products
have up to 15mm thick frontplates and are suitable for boxes
with 30mm min. depth and supply voltages of 240V 50Hz.
A 25mm deep box (862ZIC) can be used but conduit entry
is restricted.
Refer to Sentrysocket section, page 288, for more information
on active and passive control circuits.
DIMENSIONS
86 x 146mm
FIXING CENTRES
120.6mm
BS 7288:1990
All units are a.c. and pulsating d.c. fault current
sensitive devices.
Maximum total load 13A
K6231WHI
K6233WHI K6303WHI K1826WHI
K1800WHI
