355 / 759
Angle
Boxes
BLK OR WHI
2ECR4
20
20mm TWO WAY
3ECR4
10
25mm TWO WAY
2ECR4
ALL CIRCULAR BOXES
For 16mm sizes use 20mm fittings with reducers. (Ref. ER/1)
Some circular boxes are available with extended lugs for the support of heavy loads.
LOAD SUSPENSION
Standard Circular Box:
3kg. @ 60ºC max.
Extended Lug Box:
10kg. @ 60ºC max.
For enclosed lighting fittings see ‘Heat Resistant Box’ on page 356 or use ‘Steel Insert Clips’ on page 357.
Tee
Boxes
BLK OR WHI
Intersection
Boxes
BLK OR WHI
Tangent
Boxes
BLK OR WHI
2ECR5
20
2ECR5EL*
20
20mm THREE WAY
3ECR5
10
25mm THREE WAY
* Swivel lug.
2ECR6
20
2ECR6EL*
20
20mm FOUR WAY
3ECR6
10
25mm FOUR WAY
* Swivel lug.
2ECR14
20
20mm ANGLE
3ECR14
10
25mm ANGLE
2ECR15
20
20mm TEE
3ECR15
10
25mm TEE
3ECR5
3ECR6
3ECR14
3ECR15
MATERIAL:
PVCu
LID FIXING CENTRES:
50.8mm
PILLAR THREAD SIZE:
M4 (Brass inserts)
All boxes contain a moulded recess for
earth terminal.
MK Electric Catalogue
355
Technical Hotline
+44 (0)1268 563720
CABLE MANAGEMENT
CONDUIT AND
MINI
Egatube
®
Boxes
