330 / 759
Trunking
Accessories
and Plug in Cable
Terminations
(3 Pole)
1928GLV
10
2 GANG ACCESSORY
MOUNTING KIT
WITH FRAME AND
PATTRESS
1946WHI
5
2 GANG ACCESSORY
MOUNTING KIT
WITH FRAME AND
PATTRESS
1998
5
1 GANG MOUNTING
FRAME & BOX FOR ELV
ACCESSORIES
12024SLT9
10
MOUNTING FRAME FOR
2 GANG ACCESSORY
1928GLV
For fixing standard single gang
accessories to the trunking. The accessories
can be connected to the busbars by using
one of the cable termination components
or wired separately. Complete with fixing
screws.
1946
For fixing Sentrysockets, Filtered
sockets and two gang accessories to the
trunking. Supplied with busbar terminations
and cover, mounting frame and extension
pattress together with fixing screws.
1998
For fixing standard single gang
extra low voltage outlets to the trunking.
Supplied complete with enclosure box
together with all the necessary fixing
screws.
Flush
Accessory
Mounting
Frames
Data Outlets
RJ45
ELV
Blank Plates
1978WHI
5
RJ45 CATEGORY 5E
COMPUTER/DATA SOCKET
1976WHI
5
RJ45/EURO OUTLET
TWO MODULE UNSERVICED
1947WHI
5
RJ45/LJU6C OUTLET
TWO MODULE, UNSERVICED
1978 Data socket to
Category 5e.
K1976 Euro 50x50mm
(accommodates 2 outlets).
K1947 Cut out dimensions LJU6C 22x37mm
for each outlet.
1986WHI
5
ELV BOX AND COVER
Can be punched for use with any ELV
accessory that can be mounted over the
busbars.
Supplied complete with enclosure box
together with fixing screws for mounting on
to the trunking.
1978WHI
1976WHI
1986WHI
1946WHI
12024SLT9
1998
1928GLV
330
mkelectric.co.uk mkelectric.co.ukCABLE MANAGEMENT
PERIMETER AND
DISTRIBUTION
Powerlink Plus
K1925WHI
10
PLUG IN BUSBAR COUPLER
1919
5
CABLE LINK ASSEMBLY
1923WHI
10
10MM
2
CABLE TERMINATION
1924WHI
10
25MM
2
CABLE TERMINATION
K1925
Toconnect lengthsof individualbusbars
together.Rating63A.
1919
Prewiredcornercable link for internaland
externalcorners.
Rating63A.
1937
Suitable forbridging thecentral
compartment,where therearenobusbars
(Busbarsarecoupledbycablespassing
underneath).
1939
Tomaintainsegregationbetween the
walland thebusbarsorcableswhen installing
Powerlinkaroundapillarof less than125mm.
1923
Toconnect thebusbar to themainssupply
or toelectricalaccessoriesmountedonto
mounting frames.
Rating:50A.
1924
Toconnect thebusbars to themainssupply
and forconnecting thebusbarsaroundcorners
(tworequired).Rating:63A.
1924WHI
1919
1923WHI
K1925WHI
