MK Electric Catalogue No. 49

26 / 759

Aspect
1 CHANNEL
TRANSMITTER
2 CHANNEL
TRANSMITTER
Logic Plus™
1 CHANNEL
TRANSMITTER
2 CHANNEL
TRANSMITTER
WHITE K4786WHI 1 K4789WHI 1
GRAPHITE K4786GRA 1 K4789GRA 1
MOUNTING SWITCH TRANSMITTERS: All can be mounted directly to the wall surface – screws supplied. All can be mounted to back boxes – screws supplied.
Logic Plus™ and Aspect type transmitters can also be mounted using supplied adhesive pads
OPERATING FREQUENCY
868.3Mhz
IP RATING
IP2 x D
DIMENSIONS
86 x 86mm
ETSI EN 301 489-1 + -3 :
ESTI EN 300 220-3
BRUSHED STAINLESS STEEL K23476BSS* 1 K23477BSS* 1
LACQUERED BRUSHED STEEL K23476LBS* 1 K23477LBS* 1
BRUSHED CHROME K23476BRC* 1 K23477BRC* 1
POLISHED CHROME K23476POC* 1 K23477POC* 1
SATIN GOLD K23476SAG* 1 K23477SAG* 1
PORCELAIN WHITE K23476WHIW 1 K23477WHIW 1
LUSTROUS IVORY K23476LIVW 1 K23477LIVW 1
LUSTROUS BLACK K23476LBKB 1 K23477LBKB 1
POLISHED BRASS K23476PBR* 1 K23477PBR* 1
TEXTURED IRON K23476TIRB 1 K23477TIRB 1
DESERT BRONZE K23476DBZB 1 K23477DBZB 1
ANTIQUE BRASS K23476ABSB 1 K23477ABSB 1
TEXTURED COPPER K23476TCOB 1 K23477TCOB 1
Transmitters
* Available with the option of either White or Black inserts. Add Suffix ‘W’ or ‘B’ to part
number when ordering, E.g. KxxxxBSSW.
Where there is no asterix, the final suffix W = White Insert, B = Black Insert,
E.g. KxxxxWHIW = Porcelain White finish with White inserts
LEAD TIMES
Please contact our Customer
Services Department on:
01268 563 404
FINISHES
OPERATING FREQUENCY
868.3Mhz
IP RATING
IP2 x D
DIMENSIONS
86 x 86mm
ETSI EN 301 489-1 + -3 :
ESTI EN 300 220-3
OPERATING FREQUENCY
868.3Mhz
IP RATING
IP2 x D
DIMENSIONS
86 x 86mm
ETSI EN 301 489-1 + -3 :
ESTI EN 300 220-3
OPERATING FREQUENCY
868.3Mhz
IP RATING
IP2 x D
DIMENSIONS
86 x 86mm
ETSI EN 301 489-1 + -3 :
ESTI EN 300 220-3
FINISHES
26
WIRING DEVICES
WIRELESS
EchoTM
