EURO DATA ENCLOSURE
l
IP56
PACK QTY
1
gang 2 euro module enclosure
1
9722
2
gang 4 euro module enclosure
1
9724
Dimensions
1
gang 126mm (Height) x 96mm (Width) x 81mm (Depth)
2
gang 143mm (Height) x 164mm (Width) x 81mm (Depth)
The Sockets retain their IP56 rating when in use providing the lid is closed fully
Supplied as ready assembled units, with two earth terminals in the back box
Knockouts - 1 gang 4x 20mm Dia, one on each edge
2
gang 6x 20mm Dia, two on the top and bottom, and one on each side
DATA AND CO- AXIAL MODULES
l
PACK QTY
BNC single module with 75 Ohm crimp connector
25
7074
TV outlet (male)
25
7065
TV outlet (female)
25
7067
F type satellite
25
7069
Triplex Unit (TV, FM, Sat)
25
7063
TV outlet screened, return
25
7060
Phono (female)
25
7087
Quadplexer (TV, FM, Sat 1 & Sat 2)
10
7066
Quadplexer with TV return
10
7064
(
TV, TV return, FM, Sat 1 & Sat 2)
Also available in Black - Add suffix
BK
to list No.
ie: Triplex unit in black = 7063/
BK
.
Dimensions
25
mm x 50mm (1 Module)
(
except 7063 & 7066 - 50mm x 50mm)
(
except 7064 - 75mm x 50mm 3 Module)
COMMUNICATION MODULES
l
PACK QTY
BT Master Voice
25
7080
BT Master Voice, Left Handed
25
7080/
LH
BT Secondary Voice, 6 wire
25
7071
RJ45 (single) module, 8 wire - Category 5e
25
7172
RJ45 ISDN terminated
25
7174
RJ11/12
25
7086
PABX Voice
25
7176
RJ45 (Twin) module
25
7173
1
/
2
module size
25
7081/2
1
module size
25
7081
2
module size
10
7082
Also available in Black - Add suffix
BK
to list No.
ie: BT Master in black = 7080/
BK
.
Dimensions
25
mm x 50mm (1 Module)
9722
9724
7064
7066
7069
7065
7067
7074
7063
7087
7080
7071
7172
7176
7086
7174
