ENERGY METER DIMENSIONS
C7KT1531 & C7KT1533 C7KT1543 & C7KT1545
POLESTAR COMPACT FINAL CIRCUIT METERING OPTIONS
C7KT1531
80A SP & TP DIRECT CONNECTION ENERGY METERS
l
Description LIST No
Single Phase Direct connection Energy Meter C7KT1531
Single Phase Direct connection Energy Meter (MID) C7KT1533
Three Phase Direct connection Energy Meter C7KT1543
Three Phase Direct connection Energy Meter (MID) C7KT1545
• Direct Connect kWh meter
• Pulsed Output
• DIN rail Mounting
• 35mm2 terminal capacity
• Green Backlit display
CARLO GAVAZZI
kWh
M21
18MPSC125LP
DUAL METER PACKS I
‘Add on’ assemblies suitable for mounting directly beneath two surface
125A/250A type B Distribution Boards. Includes two digital energy
meters, six current transformers, all associated fuses & wiring and flexible
interconnections to Distribution Boards. Provides single point
isolation while dual meters allow for separate monitoring of Light and
small Power energy consumption.
Suitable for use with a 3ph 4 wire unbalanced system
Description 125A 250A
Height 410mm 740mm
‘Add-on‘ Dual Meter Pack 18MPSC125LP 18MPSC250LP
For use with IP3X Type B Distribution Boards
kWh Kilowatt hours
kW (S) Real Power (system)
kvarh Kilovolt amp reactive hours
kvar (S) Reactive Power (system)
PF (S) Power Factor (system)
Hz ( S) Frequency (system)
PF L1 Power Factor
PF L2 Power Factor
PF L3 Power Factor
A L1 Current
A L2 Current
A L3 Current
V L1-2 Line Voltage
V L2-3 Line Voltage
V L3-1 Line Voltage
V L1 Phase Voltage
V L2 Phase Voltage
V L3 Phase Voltage
Energy meters within all Polestar Compact final assemblies display
values of:
Non MID meters include MODBUS (RTU) connections and pulsed output
as a standard feature.
MID meters are supplied with a pulsed output as a standard feature.
