www.furse.comEarth bonds & clamps
TSC-0912 - 09.10.12
BS EN 50164-1 Class H, BS 7430
†
UL467 (CR700, CR705, CR730)
Tightening torque 12 Nm
High strength copper alloy 'U' bolt clamp designed to provide a high quality,
low resistance connection between flat tape or stranded conductor and
earth rod or rebar.
‘U’ Bolt threaded M10.
Nominal rod/
rebar diameter
Hole centres
Tape width Weight
Part
each
No.
5
⁄
8
”
16 mm
37 mm
-
0.20 kg
CR305
†
3
⁄
4
”
20 mm
37 mm
-
0.20 kg
CR310
1”
25 mm
37 mm
-
0.20 kg
CR315
5
⁄
8
”
16 mm
37 mm
25 mm
0.26 kg
CR320*
1
1
⁄
2
”
38 mm
54 mm
-
0.37 kg
CR325
2”
50 mm
64 mm
-
0.44 kg
CR330
* CR320 includes additional plate to allow tape to be clamped without drilling.
* Suitable for use with 8 mm Ø solid circular copper conductor.
‘U’ bolt rod clamp (type GUV)
Nominal rod/
rebar diameter
Conductor
range
Weight
Part
each
No.
5
⁄
8
”
16 mm
16-95 mm
2
0.39 kg
CR700*
†
3
⁄
4
”
20 mm
16-70 mm
2
0.39 kg
CR700*
†
5
⁄
8
”
16 mm
70-185 mm
2
0.39 kg
CR705
†
3
⁄
4
”
20 mm
70-150 mm
2
0.39 kg
CR705
†
5
⁄
8
”
16 mm
150-300 mm
2
0.62 kg
CR730
†
3
⁄
4
”
20 mm
150-300 mm
2
0.62 kg
CR730
†
1”
25 mm
16-70 mm
2
0.39 kg
CR710
1”
25 mm
70-150 mm
2
0.39 kg
CR740
1”
25 mm
150-300 mm
2
0.62 kg
CR750
‘U’ bolt rod clamp (type E)
BS 7430,
†
UL467 (CR305)
CR305
CR700
NEW
NEW
NEW
High strength copper alloy 'U' bolt clamp designed to provide a high quality,
low resistance connection between solid circular or stranded conductor and
an earth rod or rebar.
