AX SWITCHES - MOULDED ROCKER
LIST NO DESCRIPTION
CARTON QTY
VG3430 10AX 1 way SP
6
VG3530 10AX 2 way SP
6
VG3489 10AX Retractive
6
VG3490 10AX Retractive - bell symbol
6
VG3490/1
10
AX Retractive - fan symbol
6
•
BS EN 60669-1
•
Fully rated for fluorescent and inductive loads.
•
Retractive switches can be wired for normally open (N/O)
or normally closed (N/C) circuits.
20
AX SWITCHES - MOULDED ROCKER
LIST NO DESCRIPTION
CARTON QTY
VG3450 1 way
6
VG3451
1
way complete with key
6
VG3460 DP
6
VG3461 DP complete with key
6
VG3461ELT DP complete with key marked ‘Emergency light test’ 6
VG3469 DP marked ‘ON’
6
VG3535 Intermediate
6
VG3550 2 way
6
VG3551 2 way complete with key
6
VG3552 2 way and off
6
VG3940 Spare key
6
•
BS EN 60669-1 • Fully rated for fluorescent and inductive loads
(
except List No.VG3552).
ANCILLARY ITEMS - MOULDED
LIST NO DESCRIPTION
CARTON QTY
VG3435 Cord outlet - 10mm diameter aperture, complete
with earthing terminal and cable clamp
6
VG3436 Fuse unit fitted with 13AASTA certified fuse link 6
VG3491 Indicator - Red
6
VG3492
Blanking component
6
VG3493 Indicator - Green
6
VG3494 Indicator - Amber
6
•
BS 5733 (Where Applicable)
VG3430 VG3490 VG3490/1
VG3450
VG3535
VG3551
VG3460
VG3550
VG3435
VG3491
VG3493
VG3436
VG3492
VG3494
LIST NO MARKING CARTON QTY LIST NO
MARKING CARTON QTY
VG3460BO
BOILER
6
VG3460HT
HEATING SYSTEM
6
VG3460HD
COOKER HOOD
6
VG3460MW
MICROWAVE
6
VG3460DW
DISHWASHER
6
VG3460TD
TUMBLE DRYER
6
VG3460EF
EXTRACTOR FAN
6
VG3460WD
WASTE DISPOSAL
6
VG3460FR
FRIDGE
6
VG3460WDR
WASHER DRYER
6
VG3460FZ
FREEZER
6
VG3460WM
WASHING MACHINE
6
VG3460FF
FRIDGE FREEZER
6
VG3460WA
WATER HEATER
6
VG3460HB
HOB
6
Marking to customer specification also available
20
AX DOUBLE POLE SWITCH MARKINGS
VG3901
VG3904
GRIDS COMPLETEWITH EARTH TERMINAL
LIST NO DESCRIPTION
CARTON QTY
VG3901 1 gang
20
VG3902
2
gang
20
VG3903
3
gang
10
VG3904
4
gang
10
Dimensions
1-2
gang 81mmx58mm
3-4
gang 141mmx58mm
When required for surface mounting assemblies, the fixing ears
should be removed or bent downwards at 90˚.
