ALECTRA
Consumer Units
Specification
Polystyrol Body
Secure DIN Rail on keyhole fixing for rapid wiring
Busbar shroud for added safety
Designed in the UK to BS5486 Part 13: 1989
Assembled in the UK to BSEN 60439-3
Degree of protection IP40 to BSEN 60529
Flexible/High Integrity Accepts Protek’s
6KA MCBs
Protek’s 6A to 63A 6KA single module RCBOs
Protek’s 6A to 40A 6KA SpaceSaver RCBOs
Features & Benefits
NEW Size:
Increased height allows more cabling
space
Flexible/
All 17th Edition boards have a busbar
High-integrity:
for two RCBOs off the main isolator
and the second RCD can be
positioned to suit requirements
Full 17th Edition:
Using isolators and RCBOs gives full
compliance
Choice of incomers:
RCD, Isolator, Time Delayed RCD
Busbar cut to
Allows various configurations along
size on site:
with contactors, timers, bell
transformers etc. to be fitted on site
Meter ready:
Selection of KWH meters available
including MID meters
Surge Ready:
TT or TNS available
Solar ready boards:
Fitted with MID approved meter, RCD
and isolator for new installations
(surge units can also be added)
Interior
A410
10
210
245
110
A414
14
210
310
110
A422
22
210
440
110
Code No. of Modules Height mm Width mm Width mm
Protek Electronics
Tel: 01543 46 75 75 Fax: 01543 46 23 70 Email:
Web:
A17/16-80
AIS-008
